745BTS-R000NDBP2
Chassis Supermicro CSE-745BTS-R000NDBP2 4U/Tower 1200W Redundant 8xHDD SATA/SAS
Manufacturer: Supermicro
Part number: 745BTS-R000NDBP2
UPC/EAN: 672042284900
Availability*: On order (estimated delivery time from 10 to 21 business days)
* Please remember that delivery times are also influenced by events beyond our and the manufacturer's control, such as random events, armed conflicts or natural disasters.
Delivery cost: 30,00 zł net (36,90 zł gross)
(the indicative cost of delivery on Poland's territory)
The indicative delivery cost in EU - 30&euro
More info at manufacturer site
Broken link? Report us.
Log in to add a review.
Kluczowe cechy / Key features :
1. Intel Xeon 6 SoC with P-Cores, 36C, Media Transcoding Accelerator at 235W
2. Support for up to 1 triple-width PCIe GPU or 2 double-width PCIe GPU accelerator cards
3. Up to 4 DIMMs supporting up to 256GB DDR5-6400 MT/s
4. 2x 100GbE QSFP28 +1x IPMI shared LAN 1x GbE RJ45
5. Up to 1x PCIe 5.0 x16 FHFL + 1x PCIe 5.0 x 16 FHFL or 2x PCIe 5.0 x8 FHFL + 1x PCIe 4.0 x8 FHFL + 1x PCIe4.0 x2 (physical x4)
6. Up to 16 front fixed 3.5"/2.5" NVMe/SAS/SATA drive bays
7. 2 Redundant 1200W Titanium Level Hot-plug power supplies
Product description
We try to be as accurate as possible, however we do not guarantee that the product descriptions on our site are current or error free.
Please verify them on the manufacturer's website by clicking this link.
| Manufacturer | Supermicro |
|---|---|
| SKU | CSE-745BTS-R000NDBP2 |
| Basic informations | |
| U size | 4U/Tower |
| Expansion slots # | 4 |
| Motherboard formats support | ATX |
| Motherboard sizes support | 12" x 9.6" |
| Power Supply | |
| Redundant power supply | Yes |
| Power supply power | 1200 W |
| Power supply type | AC |
| Drives | |
| Hot-Swap | No |
| Max. drives # | 8 |
| 3,5" drives support | Yes |
| 2,5" drives support | Yes |
| SATA support | Yes |
| SAS support | Yes |
| SAS type | SAS2 |
| CD/DVD drive installation possibility | No |
| SAS controller required | No |
| Other | |
| Application | High-efficiency, Cost-effective |
Product description errors? Please let us know.
